| Technical Parameters | |
|---|---|
| Overall dimension | 2540*1330*1990mm |
| Passengers capacity | 2 |
| Max. speed | 40km/h & 25mph |
| Max. travelling range | 80-100km |
| Slope climbing capacity | 30% |
| Turning radius | ≤3.8m |
| Ground clearance | ≥120mm |
| Brake distance | ≤4m |
| Wheelbase | 1700mm |
| Front/Rear tread | 960/980mm |
| Weight | 520kg |
| Tire | 12-inch road tires, with aluminum wheels |
| Electric System | |
|---|---|
| Motor | AC, 48V, 5kW |
| Controller | 48V, 350-400A |
| Battery type | Lead acid battery, 150Ah, 8V*6pcs |
| Charging time | 6-8 hours |
| Braking system | Front/Rear disc brake, EMB system |
| Front axle and suspension | Independence suspension |
| Rear axle and suspension | Torsion beam |
| Steering | “Rack & Pinion” steering |
| Exterior | |
|---|---|
| Display | LCD instrument, show time, speed, driving range, battery capacity, etc |
| Light | Front & rear combination LED lights |
| Seat | Bus cold foam sponge + high-resilience PU leather fabric |
| Body material | Steel frame + ABS engineering plastic molding material |
Revolutionizing Your Ride with Electric Power.
